Main technical parameters
Specification:	TRE-1025	TRE-1024
Quantity of blade	16	20
Dimension of blade{Diameter x Thickness}(mm)	460x50	560x60
Speed of blade(r/min)	18	25
Capacity(kg/h)	1500	3000
Size of feed-in materials	Whole tyre below 750﹟(removed bead)	Whole tyre below 1200﹟(removed bead)
Size of discharged materials	50mm rubber strip or 50x50mm rubber lump	60mm rubber strip or 60x60mm rubber lump
Power of main motor(KW)	37-45	55-75
Specification of decelerator	ZSY hard column-gear type	ZSY hard column-gear type
Velocity ratio	56	39
Rotational speed of screen(r/min)	4-10	4-9
Power of screen(KW)	4	5.5
Dimension(mm)	4200 x 2100 x 2300	6000 x 2800 x 3700
Weight(kg)	approx  7500	approx  16000
